The HDSS-6020 Self Stick Duct Door provides easy access to sheet metal ducts by utilizing an innovative self stick frame for easy installation. The door panel is insulated, single cam, continuous aluminum piano hinge. The HDSS-6020 is tested to 10" SP with minimal leakage.
Model No.
Door Size W x H
Duct Opening
Latches
Price *
HDSS-6020
6x6
4-1/2X4-1/2
1
$18.99
HDSS-6020
8x8
6-1/2X6-1/2
1
$19.99
HDSS-6020
10x10
8-1/2X8-1/2
1
$21.99
HDSS-6020
12x12
10-1/2X10-1/2
1
$22.99
HDSS-6020
14x14
12-1/2X12-1/2
2
$26.99
HDSS-6020
16x16
14-1/2X14-1/2
2
$30.99
HDSS-6020
18x18
16-1/2X16-1/2
2
$38.99
HDSS-6020
20x20
18-1/2X18-1/2
2
$52.99
HDSS-6020
24x24
22-1/2X22-1/2
2
$54.99
* Plus shipping
and handling.
(Free Shipping at 50+ doors)
Insulation: Door panel filled with 1" fiberglass insulation
Gasketing: 1/8" thick by 1/2" wide closed cell neoprene gasketing between door and frame. 1/8” thick by 1-1/2” wide adhesive bonded gasket between frame to duct
Latch: Self tightening, hand operated cam latches
Hardware: Hex head sheet metal screws
See also:
Fire Stopping Sealants - Fire Stopping Sealants - Recommended for fire rated applications
The HDSS-6020 Self Stick Duct Door provides easy access to sheet metal ducts by utilizing an innovative self stick frame for easy installation. The door panel is insulated, single cam, continuous aluminum piano hinge. The HDSS-6020 is tested to 10" SP with minimal leakage.
